Model Material Width Coil Weight Material Thickness Speed Rollers Diameters Coil ID (Ø) Control System
CL302 30 – 300 1.000 Kg 0.4 – 3 ( mm ) 32 m/min 9 Pcs. / Ø 85 mm 300 – 550 ( mm ) Servo System
CL302 30 – 300 2.500 Kg 0.4 – 3 ( mm ) 32 m/min 9 Pcs. / Ø 85 mm 420 – 550 ( mm ) Servo System
CL402 40 – 400 2.500 Kg 0.4 – 3 ( mm ) 32 m/min 9 Pcs. / Ø 85 mm 420 – 550 ( mm ) Servo System
CL602 60 – 600 2.500 Kg 0.4 – 3 ( mm ) 32 m/min 9 Pcs. / Ø 85 mm 420 – 550 ( mm ) Servo System
CL304 30 – 300 4.000 Kg 0.4 – 3 ( mm ) 32 m/min 9 Pcs. / Ø 85 mm 480 – 530 ( mm ) Servo System
CL404 40 – 400 4.000 Kg 0.4 – 3 ( mm ) 32 m/min 9 Pcs. / Ø 85 mm 480 – 530 ( mm ) Servo System
CL604 60 – 600 4.000 Kg 0.4 – 3 ( mm ) 32 m/min 9 Pcs. / Ø 85 mm 480 – 530 ( mm ) Servo System
Equipped With
Mechanical Decoiler
Coil Capacity ( 1 Ton / 2.5 Ton / 4 Ton )
Mechanical Coil Tightening / Releasing
Coil Upper Pressure Arm
Coil Routing Platform
Coil Bending Arm
Servo Feeder with Straightener
Roller Group – Gear Transmission
Straightening Adjustment / Accurate Positioning
Automatic Mold Height Adjustment
Automated Straightening / Servo System
Distance Detection / Laser Sensor
Mold Memory & Multiple External Outputs
Operating from Touchscreen Panel and Remote Tech Support
Encoder
Press Control Automation System
Mold Protection System
Mold Lubrication System
