HHP 80 Horizontal Hydraulic Press

HHP Series	Unit	HHP 10	HHP 20	HHP 30	HHP 40	HHP 50	HHP 80	HHP 100
Max pressure at 200 Bars	TONS	11	22	33.1	44.1	55.1	88.2	110.2(at 250bar)
Oil tank capacity	Gallons	3.17	3.17	10.57	10.57	15.85	31.7	31.7
Bending Capacity for Flat Material	in	5.91”x0.31”	7.87”x0.47”	7.87”x0.71”	7.87”x0.94”	11.81”x0.59”	–	–
Bending Capacity for Round Tubes	in	1.65”x0.13”	1.89”x0.16”	2.36”x0.16”	2.36”x0.2”	2.99”x0.16”	–	–
Max Stroke	in	7.28”	7.28”	11.22”	11.22”	11.22”	11.22”	11.22”
Diameter of bolts	in	2.36”	3.15”	3.15”	3.15”	3.54”	4.13”	4.13”
Height of Toolings	in	4.13”	7.87”	9.84”	9.84”	11.81”	11.81”	11.81”
Working Speed	IPS	0.39	0.39	0.39	0.39	0.39	0.39	0.39
Return Speed	IPS	0.39	0.39	0.39	0.39	0.39	0.39	0.39
Motor Power	Hp	1.48	2.95	4.02	5.36	7.38	13.41	13.41
Net weight	lbs	551.2	1168.4	2314.8	2314.8	3196.7	3747.8	3747.8
Size of the table (LxW)	in	17.72”x35.43”	18.9”x41.73”	25.98”x49.21”	25.98”x49.21”	23.62”x49.21”	29.53”x56.1”	29.53”x56.1”
Working Height	in	36.02”	36.61”	36.61”	36.61”	36.61”	36.61”	36.61”
Length	in	35.43”	45.28”	49.21”	49.21”	55.12”	56.3”	56.3”
Width	in	17.72”	18.9”	25.59”	25.59”	23.62”	29.53”	29.53”
Height	in	44.49”	47.24”	49.21”	49.21”	59.06”	57.09”	57.09”

Flat Bar Bending Tool	Pipe Bending Tool	Straightening Tool

Bolt Punch	30 Degree Bolt Punch	Multi Vee Die

Radius 1-5-10 Punches	Radius 1-5-10 Punches	V-Dies ( V50,V63,V80,V100,V125,V160 )

Standard Configurations
